Main Photo
Category:  Rear Derailleurs
Name:  Shimano Tourney
Brand:  Shimano
Primary Group:  Tourney
Model:  RD-TY20SS
Years:  N/A
Country:  Japan
Weight:  274 grams
Added By: checker on 03/04/17
Updated By: checker on 03/04/17
Additional Photos - click for full size
Shimano Tourney
Outer Plate MarkingsShimano SISInner Plate MarkingsRD-TY20 Shimano Singapore OI
MaterialPlastic; SteelDesign CategorySlant parallelogram
Attachment Bolt Size5mm Allen KeyCable Attachment Bolt Size9mm Wrench
Shifting SystemsShimano SIS
Shimano STI
Friction
Cable AdjusterYes
Cage LengthMediumMax Cog Size28
Max Chain Wrap
General Information

Quality:Rarity:


See Incorrect Information? Log-in to submit report.
Additional Resources
Resources:Reference & ChartsCatalogs
Component Groups
Primary Group NameBrandQuick InfoBrowse Group Components
TourneyShimano1972 - , RecreationView 10 Components
Brand Information(click to expand)

Shimano Model Number Prefix List:

BB Bottom Bracket BL Brake Lever BR BRake
CB Coaster Brake CJ Cassette Joint CN ChaiN
CP Chain Protecto CR Chain Ring CS Cassette Sprockets
DF chain DeFlector DH Dynamo Hub FC Front Crank
FD Front Derailleur FE Fork Ends FH FreeHub
FS Front Suspension HB HuB HD HanDle bar
HP Head Parts (Head Set) HS Handle Stem IF Inter-3 Freehub
LP LamP MF Multi Freewheel PD PeDal
RD Rear Derailleur RH Rollerbrake Hub RM RiM
RR ReflectoRs RS Rear Suspension SB Shift Brake lever (Nexus, ?)
SC Speed Calculator (cycle computer) SF Single Freewheel Freilaufritzel SG Speed chanGe hub
SH SHoes SL Shift Lever Schalthebel SM SMall parts
SP Seat Post SQ Seat Quick release SS Single Sprocket
TL TooL WH WHeel ST Shift Brake Lever (STI, Rapid Fire, etc)
