Campagnolo 1049/A, Strada Super Record - no flute arm, etched logo (Triple)
Back
Report
Main Photo
Category:  Cranksets
Name:  Campagnolo 1049/A, Strada Super Record - no flute arm, etched logo (Triple)
Brand:  Campagnolo
Primary Group:  Super Record
Model:  1049/A (Triple)
Years:  Late 1980's - Early 1990's
Country:  Italy
Added By: Tombo on 07/05/18
Updated By: sulka on 03/07/20
Additional Photos - click for full size
Campagnolo 1049/A, Strada Super Record - no fCampagnolo 1049/A, Strada Super Record - no f
 Verify Component Photos
Chainring CountTripleBCD 144mm
BB StyleSquare Taper (ISO)Pedal Threads9/16" x 20 (English)
BB Length ??Flutes Spider
Lengths 170Arm/Spider MaterialAluminum Alloy
Front MarkingsCampagnolo ShieldBack Markings[length] Strada [production date code]
Extractor Threading 22x1mm (Standard)
General Information
Late model Campagnolo Super Record crankset without the fluting on the crank arm.
Many of the examples I have found have a date code of 21 inside a square, which translates to 1986. Starting in 85 it appears that Campagnolo took on a square with a two digit number inside.  [11] = 1985, [21] = 1986, etc.  [61] was 1990.
A few of these style cranks still had an engraved style campagnolo logo, there after they used a laser etched logo which often wore off from use.  There is a confirmed case of the etched logo with a 1986 date code.



Quality:Rarity:


See Incorrect Information? Log-in to submit report.
Additional Resources
Resources:Reference & ChartsCatalogsExternal ResourcesGear Calculator
Component VariationsView Detailed List  Manage Variations
Variations of Component exist (Component is 1 of 4)BrandGroup
Campagnolo 1049/A, Strada Super RecordCampagnoloSuper Record
Campagnolo 1049/A, Strada Super Record - no flute arm, engraved logoCampagnoloSuper Record
Campagnolo 1049/A, Strada Super Record - no flute arm, etched logoCampagnoloSuper Record
Component Groups
Primary Group NameBrandQuick InfoBrowse Group Components
Super RecordCampagnolo1974 - 1987, Road RaceView 43 Components
